?????????產品中心

E4 XANDY AX108 ROSY讀出系統

金剛石探測器

市場價:￥0.00

價格:￥0.00

XANDY is the data acquisition system, power controller and monitoring unit for the Diamond XBPM? detector. It provides the measurement of the 4 quadrants, A, B, C, D of the XBPM? detector as well as the intensity and relative position of the X-ray beam in x and y at experimental beam lines of Synchrotron Light Sources. Results are transferred from the embedded Linux-based device server via Ethernet to the control system or to the desktop, where the browser-based GUI provides easy access to the data for on-line monitoring. Parameters: Type: XANDY AX108 Number of channels: 4 Embedded amplifiers: Switch amplifier Data rate: 1 - 10 - 100 kHz Data resolution: 24 bit Output: Output: A, B, C, D, x, y, I Data format: 32 bit Interface: Browser-based GUI API: Epics, Tango Communication rate: 1 Hz to control system I/O connections: A, B, C, D four analogue inputs with BNC connectorsExTrigg analogue input for external trigger DAC 1 & 2 analogue output for feedback to beam controlBias output for detector bias voltageLAN for remote connection2 USB socketsHDMI for monitor Power supply: Integrated power supply for XBPM? detector +50 V @ 1 mA 2 DAC output, 16 bit, ?10 V Chassis: 19” Table top19” Rack mountInterfaces: Browser-based GUI for data acquisition and monitoringBrowser-based GUI for power controlAPI for communication to control systems1
超高溫放大器

金剛石探測器

市場價:￥0.00

價格:￥0.00

The Cx-HT High-Temperature Amplifier is used at temperatures up to 180? C. It is made for nuclear fusion diagnostics in Tokamak environments and for geodetical applications. The Cx-HT High-Temperature Amplifier is a spectroscopic charge integrating amplifier with a semi-Gaussian signal shape. Features: Type: Spectroscopic amplifier for high temperatures Maximum operating temperature: 180?C Gain: 2.9 mV/fC Input coupling: AC coupled (1 nF @ 1 kV) Polarity: Non-inverting, positive Power supplies: Supply voltage: +12 V @ 20 mA Bias-Tee: Integrated Maximum Bias voltage: ?500 V
MNTB7-HT 金剛石快中子一體化探測器

金剛石探測器

市場價:￥0.00

價格:￥0.00

The MNTB7-HT Axial Instrumented Diamond Neutron Monitor integrates detector and spectroscopic amplifier in one solid stainless-steel housing. The Axial Detector can be operated up to 180° C. The sensing volume of the single-pad detector can be enlarged to 9 diamond sensors. FEATURESDetector type:Axial - Instrumented Diamond Neutron MonitorNumber of sensors:1 or 4 or 9 sCVD sensorsOutput signal:Semi-Gaussian with 250 ns FWHMSupply voltages:+12 V for amplifier, +50 V for sensor biasMaximum operating temperature:180° COPTIONSThe Axial Instrumented Neutron Monitor can be provided as self-standing monitoring system:<ul style="color: rgb(97, 92, 92); font-family: localFont1, "Times New Roman", Helvetica, Arial, sans-serif; font-size: 18px; white-space: normal;" class=" list-paddingleft-2"><li>Fast-Neutron Monitoring System including ROSY? AX106 with integrated power supply and Neutron Spectroscopy Application for real-time neutron monitoring.</li></ul>
塑料閃爍體

有機閃爍體

市場價:￥0.00

價格:￥0.00
液體閃爍體

有機閃爍體

市場價:￥65.00

價格:￥60.00
ALPHA/BETA DETECTION

有機閃爍體

市場價:￥0.00

價格:￥0.00
無機閃爍體

無機閃爍體

市場價:￥0.00

價格:￥0.00
A1金剛石束損監測器

CIVIDEC束線裝置

市場價:￥0.00

價格:￥0.00

Machine Protection – Bunch-by-BunchThe A1 Diamond Beam Loss Monitor is used to measure beam losses at particle accelerators. It is designed for beam loss diagnostics and machine protection of all types of particle accelerators (e.g. synchrotrons and linear colliders for high-energy physics, electron accelerators for synchrotron light sources, medical accelerators for hadron therapy).  The system measures fast AC beam losses from bunched beams simultaneously with continuous DC beam losses. It is sensitive to single MIP particles and has a very high dynamic range. Bunch-by-bunch losses are resolved in real time with the ROSY? Beam Loss Application. ROSY? AX106 is designed to be integrated into any control system.
A2金剛石束線位置監測器

CIVIDEC束線裝置

市場價:￥0.00

價格:￥0.00

A2 DIAMOND BEAM POSITION MONITORLocating Charged Particle BeamsThe A2 Diamond Beam Position Monitor is made to precisely measure the beam position of charged particle beams. It is used in fixed experimental beam lines at high-energy physics laboratories, in order to measure and control the beam position and intensity. The position of bunched as well as continuous charged particle beams is measured with this beam position monitoring system.  The energy loss and lateral scattering is kept to a minimum with the beam-intercepting four-quadrant pCVD detector.
A5金剛石能譜儀

CIVIDEC束線裝置

市場價:￥0.00

價格:￥0.00

A5 DIAMOND SPECTROMETERThe Heavy-Ion SpectroscopeThe A5 Diamond Spectrometer is designed for high-precision spectroscopy of heavy ions. It is used for research in radiochemistry, nuclear medicine and heavy ion physics. The Diamond Spectrometer is a robust spectroscopy tool which can be used in hot environments as well as in vacuum applications. The system provides an energy resolution of 20 keV FWHM, intrinsically matched to the spectroscopic properties of diamond detectors. Energy straggling of the heavy ions is kept to a minimum by the dedicated technology.
A6金剛石相位監測器

CIVIDEC束線裝置

市場價:￥0.00

價格:￥0.00

The Heavy-Ion SpectroscopeThe A5 Diamond Spectrometer is designed for high-precision spectroscopy of heavy ions. It is used for research in radiochemistry, nuclear medicine and heavy ion physics. The Diamond Spectrometer is a robust spectroscopy tool which can be used in hot environments as well as in vacuum applications. The system provides an energy resolution of 20 keV FWHM, intrinsically matched to the spectroscopic properties of diamond detectors. Energy straggling of the heavy ions is kept to a minimum by the dedicated technology.
A3 金剛石快中子監測器

CIVIDEC中子診斷

市場價:￥0.00

價格:￥0.00

The Fast-Neutron CounterThe Diamond Fast-Neutron Monitor is designed for neutron flux monitoring in fusion reactor applications. High neutron flux rates are measured with the C2-HV Broadband Amplifier, while high-precision neutron spectroscopy is performed with the Cx-L Spectroscopic Amplifier. Both amplifiers allow the installation of a 10 m long detector cable between detector and amplifier, for operation in high-radiation environments.
A7金剛石熱中子監測器

CIVIDEC中子診斷

市場價:￥0.00

價格:￥0.00

A7 DIAMOND THERMAL-NEUTRON MONITORThe Thermal-Neutron CounterThe A7 Diamond Thermal-Neutron Monitor is designed for the measurement of the neutron flux in thermal neutron beams. A highly enriched 6LiF layer is used as thermal neutron converter, where the 6Li(n,α)3H reaction is used for neutron detection. The monitor is optimized for high count rates and allows using cables up to 10 m length between detector and amplifier, to enable the usage in high-radiation environments.
A8金剛石質子反沖望遠鏡

CIVIDEC中子診斷

市場價:￥0.00

價格:￥0.00

A8 DIAMOND PROTON RECOIL TELESCOPEFast-Neutron SpectroscopyThe A8 Diamond Proton Recoil Telescope is designed to measure the neutron flux in high-energy neutron beams with highest precision. It is used for the neutron beam monitoring in mono-energetic fast neutron beams at Van de Graaff and Tandem accelerators. The detection of fast-neutrons is based on the well known 1H(n,p)n reaction, where the neutron energy is determined by measuring the energy deposited in the Diamond Telescope Detector by proton recoils.  The ROSY? AX106 readout system completes the A8 Diamond Proton Recoil Telescope to a ready-to-use neutron beam monitoring system. It provides real-time neutron spectra of all 4 telescope sensors for monitoring purposes, as well as the real-time coincidence spectrum of the proton recoils.
A4 金剛石XBPM監測器

CIVIDEC X射線診斷

市場價:￥0.00

價格:￥0.00

A4 DIAMOND XBPM MONITORMonitoring X-ray Beams with Highest PrecisionThe A4 Diamond XBPM Monitor is developed for high-precision X-ray beam diagnostics. It is used at experimental beam lines of Synchrotron Light Sources for beam position and beam intensity monitoring. The high transparency and the phantastic spatial resolution makes it perfectly suited as monitor for soft as well as hard X-ray beams. The ROSY? AX106 readout system completes the A4 Diamond XBPM Monitor to a ready-to-use diagnostics system at Synchrotron Light Sources. Its dedicated XBPM Application provides real-time diagnostics of the beam position, intensity and profile at high analogue bandwidth. A controller for the horizontal and vertical X-ray beam position is provided with two 16-bit DAC outputs.
B14 金剛石望遠鏡探測器

CIVIDEC金剛石探測器產品線

市場價:￥0.00

價格:￥0.00

Fast-Neutron Beam MonitoringThe B14 Diamond Telescope Detector was developed for proton-recoil measurements in fast-neutron beams for neutron flux monitoring. The detector consists of four diamond sensors, which are mounted directly behind each other as telescope. The B14 Diamond Telescope Detector is specialized for ΔE/E measurements, where the absence of material between sensors is of highest importance. The thickness as well as the number of the diamond sensors in the B14 Diamond Telescope Detector can be adapted to specific applications.
